Время срабатывания при давлении от 13,5 до 14 МПа: 0,03 сек.
Размерная Диаграмма
Код заказа
HPPｰVB2V
Model | Displacement (㎝3/rev) | Pressure adjustment range (MPa) | Rotating speed (min-1) | ||
Flange type | Rated | Max. | Lowest | ||
HPPｰVB2VｰF8A3 (ｰ EE）ｰB | *to 8.0 | 1 to 7 | 1,800 | 2,500 | 500 |
HPPｰVB2VｰF8A5 (ｰ EE）ｰB | 3 to 14 | ||||
HPP-VC2V
Model | Displacement (m3/rev) | Pressure adjustment range (MPa) | Rotating speed (min-1) | ||
Flange type | Rated | Max. | Lowest | ||
HPP-VC2V-F14A3（-EE）-B | *to 14.5 | 1 to 7 | 1,800 | 3,000 | 500 |
HPP-VC2V-F14A5（-EE）-B | 3 to 14 | ||||
