Model no. | Rated pressure | Maximum pressure MPa | Capacity (l/min at rated pressure) | Driving power (kW) (at rated pressure, 1800 1/min) | Minimum/maximum rotational speed (1/min) | |||||||
Rot. speed (1/min) | MPa | Rotational speed (1/min) | |||||||||||
1000 | 1200 | 1500 | 1800 | ||||||||||
QX22 | | -4 | 1500 | 9.8 (100) | 13.7 (140) |
|
| 5 | 6 |
| 1500–1800 | ||
1800 | 12.7 (130) | 17.7 (180) | |||||||||||
QX22 | -5 -6.3 -8 | 1000 | 7.8 (80) | 9.8 (100) |
|
| 6 8 10 | 8 10 13 | 1.9 3.8 4.6 |
1000–1800 | |||
1200 | 9.8 (100) | 12.7 (130) | |||||||||||
1500 | 20.6 (210) | 24.5 (250) | |||||||||||
1800 | 20.6 (210) | 24.5 (250) | |||||||||||
QX32 | -10 |
20.6 (210) |
24.5 (250) | 7 | 9 | 12 | 15 | 5.7 | |||||
-12.5 | 10 | 12 | 16 | 20 | 6.8 | ||||||||
-16 | 13 | 16 | 21 | 26 | 8.5 | ||||||||
QX42 | -20 | 15 | 20 | 26 | 32 | 10.5 | |||||||
-25 | 20 | 25 | 33 | 41 | 13.6 | ||||||||
-31.5 | 27 | 34 | 44 | 54 | 16.8 | ||||||||
QX52 | -40 | 32 | 40 | 52 | 64 | 21.5 | |||||||
-50 | 43 | 53 | 69 | 85 | 26.0 | ||||||||
-63 | 56 | 67 | 88 | 108 | 33.4 | ||||||||
QX62 | -80 | 66 | 82 | 107 | 132 | 41.8 | |||||||
-100 | 87 | 107 | 138 | 170 | 52.5 | ||||||||
-125 | 110 | 136 | 174 | 212 | 65.9 | ||||||||
