• * Подходит для широкого спектра гидравлических жидкостей
Type | OMT
| OMT
| OMT
| OMT
| OMT
| OMT
| ||
Motor size | 160 | 200 | 250 | 315 | 400 | 500 | ||
Maximum torque | Nm [lbf·in] | cont. | 470 [4160] | 590 [5220] | 730 [6460] | 950 [8410] | 1080 [9560] | 1220 [10800] |
int.1) | 560 [4960] | 710 [6280] | 880 [7790] | 1140 [10090] | 1260 [11150] | 1370 [12130] | ||
Maximum output | kW [hp] | cont. | 26.5 [35.5] | 33.5 [44.9] | 33.5 [44.9] | 33.5 [44.9] | 30.0 [40.2] | 26.5 [35.5] |
int.1) | 32.0 [42.9] | 40.0 [53.6] | 40.0 [53.6] | 40.0 [53.6] | 35.0 [46.9] | 30.0 [40.2] | ||
Maximum pressure drop | bar [psi] | cont. | 200 [2900] | 200 [2900] | 200 [2900] | 200 [2900] | 180 [2610] | 160 [2320] |
int.1) | 240 [3480] | 240 [3480] | 240 [3480] | 240 [3480] | 210 [3050] | 180 [2610] | ||
peak2) | 280 [4060] | 280 [4060] | 280 [4060] | 280 [4060] | 240 [3480] | 210 [3050] | ||
Maximum oil flow | l/min [USgal/min] | cont. | 100 [26.4] | 125 [33.0] | 125 [33.0] | 125 [33.0] | 125 [33.0] | 125 [33.0] |
int.1) | 125 [33.0] | 150 [39.6] | 150 [39.6] | 150 [39.6] | 150 [39.6] | 150 [39.6] | ||
Maximum starting pressure with unloaded shaft | bar [psi] |
| 10 [145] | 10 [145] | 10 [145] | 10 [145] | 10 [145] | 10 [145] |
Minimum starting torque | at maximum pressure drop cont. Nm [lbf·in] | 340 [3010] | 430 [3810] | 530 [4690] | 740 [6550] | 840 [7430] | 950 [8410] | |
at maximum pressure drop int.1) Nm [lbf·in] | 410 [3630] | 520 [4600] | 630 [5580] | 890 [7880] | 970 [8590] | 1060 [9380] | ||
